You have the RCBS Rebel on your bench but need to know exactly how to mount it and adjust the dies before your first round. This guide walks you through the specific setup steps to ensure stability and accuracy from the start.
In short: The Rebel requires a rigid bench mount to prevent flexing during sizing. You must use the 'kiss method' to set die height and adjust the primer punch depth using spent primers. Following these steps guarantees consistent headspace and proper primer seating.
Quick picks
Our shortlist for this job · tap one to see today's priceLifts the press for ergonomic comfort and provides a solid steel base that eliminates bench flex.
Allows you to trim and chamfer brass before loading, keeping your press workflow faster and cleaner.
What you need for a safe Rebel setup
Before you touch the bolt, lay out the hardware. The Rebel is a cast-iron frame with a compound linkage, meaning it is heavier than a standard press. Your bench must be rigid enough to handle that weight without flexing. It helps to understand rcbs rebel press discontinuation before going further.
- Sturdy bench: Solid hardwood, at least 1.5 inches thick, or a dedicated steel stand. Softwood or particleboard will not support the frame securely.
- Lag bolts: Large carriage bolts and washers for securing the press base. Use washers larger than the bolt head to distribute the load.
- Wrenches: Typically 1/2″, 9/16″, and 3/4″ to tighten die lock rings and base bolts. Check the manual for your specific die set.
- Machine oil: Light oil for lubricating the compound linkage pivot points. Avoid WD-40, which is not a lubricant.
- Case prep tools: A multi-tool to handle trimming and chamfering off-press. This keeps the press area clean and prevents debris from entering the primer system.
Having the right hardware ready prevents frustration during installation. A dedicated riser system can also improve your posture, reducing strain on your back and wrists over long reloading sessions.
Pro tip: If you are using a standard wooden bench, ensure the top is laminated or solid wood. Softwood or particleboard will not support the heavy cast iron frame securely. Before you buy anything, it is worth looking at rcbs rebel review.
The InLine Ultramount is made specifically for the Rebel, lifting it 9-3/4 inches to reduce strain on your back and wrists.
- *** This mount is for The RCBS Rebel Press and will ONLY work with that specific
- Lifts your press up 9-3/4" above the work surface and gets the shellplate closer to eye
Mounting the press frame securely
The most critical physical step is securing the press to the bench. A wobbly press leads to inconsistent resizing and frustrated shooters. The Rebel’s base is large, so you have plenty of surface area for mounting.
- Place the press on the bench, ensuring the handle has a full, unobstructed swing. Consider your dominant hand and where you will stand.
- Use the press base as a template to mark bolt hole positions. Use a pencil for clear marking.
- Drill pilot holes slightly smaller than your lag bolts. This prevents the wood from splitting.
- Insert the bolts with large washers under the heads and nuts. Ensure the washers sit flat against the press base.
- Tighten bolts sequentially, checking that the press does not rock or flex. Try to twist the handle by hand; there should be zero movement at the base.
Once mounted, give the handle a few full strokes. Feel the smoothness of the compound linkage. This is the heart of the press’s mechanical advantage, making sizing brass feel effortless. If it feels stiff, check for any binding on the bench top or handle obstruction.
- *** This mount is for The RCBS Rebel Press and will ONLY work with that specific
- Lifts your press up 9-3/4" above the work surface and gets the shellplate closer to eye
Installing dies and the shell holder
Now integrate your dies. The Rebel uses a standard 7/8″-14 threaded press head, compatible with virtually all reloading dies on the market. This includes RCBS, Hornady, and Lee dies.
- Clean and lubricate your new dies to remove factory preservative. Use a solvent like mineral spirits.
- Slide the shell holder onto the ram until the ball detent clicks. It should seat firmly without play.
- Screw the resizing die in by hand until it contacts the ram at the top. Do not use a wrench yet.
- Place a lubricated case in the holder and raise the ram fully to its highest point.
- Screw the die down until it firmly contacts the case mouth. This is the ‘kiss method.’
- Turn the die an additional 1/8 to 1/4 turn and lock the ring. This slight cam-over ensures full resizing.
Repeat the process for seating and crimping dies using a sized case and bullet. Always follow the specific die manufacturer’s instructions for final adjustments. Proper die setup is the foundation of your ammunition quality. It helps to understand choosing between models before going further.
Pro tip: Always check the die manufacturer's manual for specific cam-over recommendations. The Rebel's threading is standard, but die behavior can vary by brand.
Adjusting the on-press primer system
The Rebel features a reliable on-press priming system. It is sensitive but effective once set correctly. The system uses a sliding primer arm that feeds primers from a tray to the ram’s primer cup.
- Insert the correct primer cup into the ram slot. Choose small or large based on your cartridge.
- Slide the primer arm into its track; it should move smoothly without catching.
- Use the hex key to adjust the primer punch depth. Start with a conservative setting.
- Test with spent primers or dummy cases to check seating depth. The punch should seat the primer slightly below flush.
If the primer does not seat firmly, the punch is likely too short. If it dents the primer cup, it is too long. Clean the primer arm track regularly to prevent feed issues. Debris here is the most common cause of jamming.
Using a case prep multi-tool before pressing keeps the primer system clean by removing burrs and debris from the case head.
- Caliber versatility: Perfect for brass shells ranging from .17 to .45 caliber
- Multi case prep: A reloading tool for comprehensive case preparation that meets the
Common mistakes and how to fix them
Even with a solid setup, small errors can creep in. Here is how to catch them before they affect your brass.
- Loose base bolts: If the press rocks, re-tighten the lag bolts immediately. A solid mount is non-negotiable for precision. Check them every few months.
- Sticking primer arm: Debris in the track causes jams. Clean the slot with a soft brush and apply a tiny drop of oil. Avoid getting oil on the primer cup.
- Over-sizing cases: If the handle feels heavy, back the die off by 1/8 turn. The compound linkage should make sizing feel effortless. If it isn’t, you are working against the die geometry.
- Dry linkage: Lack of lubrication causes noise and wear. Apply machine oil to pivot points during every cleaning session. Wipe away excess to avoid grime buildup.
The bottom line
For a reliable setup, prioritize a rigid mount and precise die adjustments. Most shooters benefit from a dedicated riser system to improve ergonomics. Start with a simple caliber and document your settings for future reference.
- *** This mount is for The RCBS Rebel Press and will ONLY work with that specific
- Lifts your press up 9-3/4" above the work surface and gets the shellplate closer to eye
Frequently asked questions
Is the RCBS Rebel an RC1 or RC2?
The Rebel is a distinct model with its own compound linkage design, separate from the Rock Chucker series. It uses a similar threading but has a different frame and handle geometry. Loaders in this spot often ask about case head defects as well.
How much force does an RCBS Rebel press exert?
The compound linkage multiplies the force applied to the handle, allowing you to resize hard case heads with minimal hand strength. The exact force varies by die and case condition, but it is designed to feel effortless for standard calibers.
Is the RCBS Rebel still in production?
RCBS continues to manufacture the Rebel press, though availability can fluctuate. It remains a popular choice for shooters who want a robust single-stage press with on-press priming capabilities.
Can I use any dies on the Rebel press?
Yes, the Rebel uses a standard 7/8″-14 threaded head, which is compatible with virtually all reloading dies on the market from RCBS, Lee, Hornady, and others.
